6 Station Keypress Tester With Counting Function

6 Station Keypress Tester With Counting Function
6 Station Keypress Tester With Counting Function

Large Image :  6 Station Keypress Tester With Counting Function

Product Details:
Place of Origin: Dongguan China
Brand Name: OTS
Certification: CE
Model Number: Key press tester
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Strong standard wood case, inner plastic films wrapped for ISO 4918 Floor Caster Tester for PVC Flooring Testing
Delivery Time: 20 working day after getting the payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Unit/Units per Month
Detailed Product Description
Key Words: Key Press Tester Max Load: 50kg
Movement Itinerary: 0-60mm Test Frequency: 0-999999 (set Times Downtime)
Work Power: Work Power Table Weight: About 40kg
Stacking Load: 50g, 100g, 200g, 300g, 500g Weight Stack. Brand Name: OTS
High Light:

6 Station Keypress Tester

,

Eight Digit Counter Keypress Tester

,

50kg Load Lab Testing Equipment

Movement Itinerary: 0-60mm Key Press Tester / Exterior Dimension: 700*450*350






Application and Characteristics



This machine can test the buttons of NOTEBOOK (mobile phone, PDA) and various durable life tests of buttons and switches.

It can test several products at the same time (each product can be tested more), and each button can set different pressure and different height.

It is especially suitable for the fatigue test of silicone rubber button.





Technical Parameter



1. Max Load :50kg

2. Position: 6 stations (each group can be operated separately, individually controlled).

3. Movement itinerary: 0-60mm

4. Test frequency: 0-999999 (set times downtime)

5. * stacking load: 50g, 100g, 200g, 300g, 500g weight stack.

6. Adjustable speed: 10~60 /min tunable

7. Speed display: LED digital direct display

8. Test frequency: 0-999999 (set times downtime)

9. Counting function: eight digit counter, which can set up room stop function, with power off memory protection function.

10. Driving mode: Electric plus Taiwan imported linear slide structure.

11. Ways of exercise: vertical movement

12. Jig design: according to customer's product

13. Lifting function: equipped with manual adjustment of product elevating platform.

14. Exterior dimension: 700*450*350

15. Work power: 220V/50HZ

16. Table weight: About 40kg
