Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃

Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃
Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃
video play

Large Image :  Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: OTS
Certification: CE; ISO
Model Number: XB-OTS-80
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Strong standard wood case, inner plastic films wrapped
Delivery Time: 15 working days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 350 sets per month
Detailed Product Description
Product Name: Programmable Process Testing Machine High And Low Temperature Test Chamber 80L Power: 220V / 380V, 50Hz / 60Hz
Body Material: SUS#304 Stainless Steel Plate Controller: Programmable LCD Touch Screen Casters
Temperature Range: Temp Range From -20℃ To 150℃ Heating,Cooling Rate: 5.0 C / Min ,1.2 C / Min
Inner Chamber Size: 400*500*400mm Humidity Range: Without
High Light:

thermal cycling test equipment


thermal cycling chamber

Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃





  Product name Programmable process testing machine high and low temperature test chamber 80L Model Number XB-OTS-80
  Power 1∮ AC220V±10% 50Hz Weight 180kg

Interior size



Exterior size


110(W)×168(H)×110 (D)cm
  Customized size acceptable Cooling type Air cold
  Temperature range -20℃ ~150℃ Humidity range Without
  Temp control fluctuation ≤±0.5℃ Indication resolution 0.01℃
  Temp. Uniformity ≤±2℃ (Put 9 sensor into inner chamber with 9 different location to get uniformity )
  Heat up&Cool down time ≤5℃/min for heating; ≤ 1.2℃/min for cooling;
  Chamber materials

SUS#304 stainless steel for Inner chamber with thickness 1.5mm

Steel plate for external chamber with thickness 1.5mm




Rigid polyurethane foam + ultrafine glass fiber with thickness of 100mm

Hinged door, single door open in the central cabinet ( the front of the chamber)Heat distribution on the door (automatic adjustment) anti-frost, anti-condensation insulating glass observation window

Door electric equipment (automatic adjustment) anti-frost, anti-condensation device

Preparation inside the door lights (LED longevity and efficient light source)

  Features 1.Has the USB download function, with RS232 interface, the curve of the software, do not need recorder
2.With vacuum glass observation window, direct observation of the function more effectively
3.The refrigerant servo control valve flow calculation. Save electricity 30%, dormancy in flow time, energy savingmore than 50%
4.Preventing electromagnetic interference by SGS certification controller;At least 32 digital soft path matching with The Times development and software upgrade function
5.Defrost cycle (800 cycle defrost time, defrosting guarantee within 2 hours each time, integration test reach 25% of the energy saving province electricity)
  1. Battery
  2. Vehicles
  3. Chemical
  4. Aerospace
  5. Metal Parts
  6. Electronics
  7. Car Spare Parts
  8. Building Materials
  9. Communication Equipment
  10. Plastic Rubber Products




Programmable Thermal Cycle Test Chamber Temp Control Fluctuation ≤±0.5℃ 0





GB11158 GB10589-89 GB10592-89 GB/T10586-89 GB/T2423.22-2001 GB/T2423.1-2001 GB/T2423.2-2001 GB/T2423.3-93 GB/T2423.4-93 ASTM D1735 IEC60068-2-1.1990 IEC60068-2-2.1974 IEC 68-2-30 IEC68-2-03 EIA - 364-31C EIA - 364-59




Ø 24 hours online
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø Oversea offices
Ø Own import and export business license


Customer Support Services:

Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair



Our Company:


OTS was established in 1978, with over 35 years’ history, is one of the leading companies solely dedicated to manufacture of environment,class,mechanics,package testing equipment...
(such as constant temperature and humidity chambers, environmental chambers, thermal shock test
chambers,fast change rate chambers, yellowing resistance aging test chamber, salt spray chamber,
tensile testing machine, universal testing machine,carton compression testing machines, bursting
strength testing machine, vibration test, etc.) ...



Package and shipment:


(1). Strong standard wood case, inner plastic films wrapped for Programmable process testing machine high and low temperature test chamber 80L.

(2). Usually we delivery the equipment by air,by sea or by express. it depends on customer.





1. Do you offer after-sales service? How can I ask for that? And how about the warranty?

Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers.


If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.


2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.

3.How to install and use the product?

We will send you operating instructions, English video by Email. Or you can download on our officail website directly.

Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
